Choosing Heavy Duty Industrial Casters and Wheels

Selecting heavy duty industrial casters or wheels for your application, while not difficult takes some basic knowledge of the application to assure a caster that function properly while providing the longevity in the application. Time and money invested in the upfront planning will assure that the product, when purchased, will provide many years of performance with normal maintenance costs.

1. Load per caster

Knowing the load the cart/casters will be carrying is the critical first step. When you clearly understand the load, add 25-30% to that total to ensure a safe application of the product. When you have determined that total, then divide by 3. The reason for this is that no floor is perfectly flat and most times the weight is being carried on three of the four casters. Example: Load is 2000lbs times 30% equals 2600lbs. Divide 2600 lbs. by 3 and the capacity per caster should be 867 lbs. This formula does not account for shock loading (dropping material on the cart). If you believe there will be shock loading in your application use a 300% factor rather than the 30% factor to figure caster capacity.

2. Speed

The next critical piece of information to obtain is the speed at which the caster will be used. While speed of transport generally has little impact on the swivel section, the design and material make up of the wheel is critical to knowing the issues with speed. While speed is important, the duration of travel time at a particular speed is also critical. The third item to consider is the speed of a particular load. A cart might travel much faster when unloaded rather than when it is loaded. Always consider the worst case scenario-fastest speed, at the highest load for the longest period of time. Many manufactures will have a test machine that duplicates the application if you cannot be comfortable with the selection.

3. Floor conditions

Always consider the condition of the floor when selecting the perfect caster for your application. New cement floors with no defects are very kind to caster applications. Old floors that have significant defects in them (1 deep and 3-4 in diameter) are very tough on casters and wheels. Every defect in the floor is an obstacle to the caster and can cause severe damage to the wheel, bearings in the wheel, swivel section or the welds.

4. Environment

In what environment is the caster application going to occur. Is it going to be inside at ambient temperatures, or is it going to be outside with higher or lower than ambient temperature? Is there a chance that the caster is going to be in a wet or moist application at regular intervals? Always consider the temperature of the environment while in use and the possibility of the caster having continued exposure to moisture. Both temperature and moisture will impact the selection of the caster, wheel and associated finish of the product.

5. Power driven vs. manual driven

How the caster is going to be moved in its environment is very important to consider when choosing the right caster for your application. Manual (human) driven application generally is less than 3 MPH and the forces that the caster will experience will be significantly decreased when manually pushed or pulled. On the other end of the spectrum is a fully powered application. Generally these applications will travel faster and the caster will experience much greater force in the day to day function. Be very careful when shopping for casters as most manufactures only provide ratings for manual applications (2-3 MPH). If you are using catalog specifications to meet a powered application you are well on your way to a premature caster failure

It is critical to specifying the correct caster to fully understand the five points above. Skilled application engineers or technical sales people can assist you when you have a difficult application. Remember the cost of a caster is not only the purchase price. It includes associated maintenance costs and down time that go along with the incorrect selection of a caster that was not made for your application. We think of casters of very simple and not requiring much thought. Buying off a spec sheet and online price shopping can be an expensive mistake. The five suggestions above provide the reader with a great place to start when specifying a caster for your application.
