Choosing the Right Caster Series

Our caster series is a combination of many factors, including top plate and height measurements, wheel diameter, width and material, bolt hole pattern, weight capacity, and caster type. Weight capacity is categorized as medium duty casters (< 900 lbs), medium heavy duty casters (900-1500 lbs ), heavy duty casters(1500-4500 lbs), extra heavy duty casters (5,000-20,000 lbs) and super heavy duty casters (> 20,000 lbs ).

By clicking on Learn More in any caster series, you can choose from a list of specifications designed for that series of caster. The purpose is to help you match the right caster to your application to provide the best value over a significant lifetime.


Series 30

Capacity: Up to 900 lbs.
Top Plate Size: 4 x 4.5
Caster Type: Kingpin



Series 51

Capacity: Up to 1500 lbs.
Top Plate Size: 4 x 5
Caster Type: Kingpinless


55 Series Caster

Series 55

Capacity: Up to 1000 lbs.
Top Plate Size: 4 x 5
Caster Type: Maintenance Free


57 Series Caster

Series 57

Capacity: Up to 1500 lbs.
Top Plate Size: 4.5 x 6.25
Caster Type: Maintenance Free


61 Series Caster

Series 61

Capacity: Up to 3500 lbs.
Top Plate Size: 4.5 x 6.25
Caster Type: Kingpinless


71 Series Caster

Series 71

Capacity: Up to 4500 lbs.
Top Plate Size: 5 x 7.25
Caster Type: Kingpinless


77 Series Caster

Series 77

Capacity: Up to 3500 lbs.
Top Plate Size: 5 x 7.25
Caster Type: Maintenance Free


80 Series Caster

Series 80

Capacity: Up to 5000 lbs.
Top Plate Size: 6 x 7.5
Caster Type: Kingpin


81 Series Caster

Series 81

Capacity: Up to 10000 lbs.
Top Plate Size: 6 x 7.5
Caster Type: Kingpinless


81 Series Caster

Series 85

Capacity: Up to 10000 lbs.
Top Plate Size: 6 x 7.5
Caster Type: Kingpin


87 Series Caster with Twergo Wheel

Series 87

Capacity: Up to 5000 lbs.
Top Plate Size: 6 x 7.5
Caster Type: Maintenance Free


90 Series Casters

Series 90

Capacity: Up to 8000 lbs.
Top Plate Size: 8.5 x 8.5
Caster Type: Kingpin


91 Series Caster

Series 91

Capacity: Up to 20000 lbs.
Top Plate Size: 8.5 x 8.5
Caster Type: Kingpinless


95 Series Caster

Series 95

Capacity: Up to 17000 lbs.
Top Plate Size: 8.5 x 8.5
Caster Type: Kingpin


99 Series Caster

Series 99

Capacity: Up to 50000 lbs.
Top Plate Size: 14 x 14
Caster Type: Kingpin
