4×2 Mold On Rubber Swivel Caster

SKU: 51-04201-70-1
  • Load rating of 350 lbs.
  • Overall height of 5.62 inches
  • Mold On Rubber - Rubber tread molded onto a wheel core, providing cushioning, shock absorption, and traction. Offers a smooth and quiet ride.

$142.84$221.68 Caster components that fall outside of a standard solution affects costs, as well as a variety of other factors explained here. Listed pricing doesn’t include optional equipment such as toe guards, or swivel locks, which can increase cost significantly. Quantity based buying can also decrease overall costs but is still subject to current market conditions.
Price range does not include options or accessories*
Engineered Casters Produced and Shipped in 4 Days

Categories: , , Tags:


Specifications

Product Type: Caster
Series: 51
Capacity: 350 lbs.
Caster Material: Steel
Wheel Material: Mold On Rubber
Wheel Configuration: Single Wheel
Wheel Width: 2"
Wheel Diameter: 4"
Caster Style: Swivel Caster
Caster Type: Kingpinless
Overall Height: 5.62"
Swivel Radius: 3.64"
Swivel Lead: 1.5"
Top Plate Size: 4 x 5
Bolt Hole Pattern: 2.625 x 3.625 Slotted to 3 x 3
Bolt Size: 0.375"
Bearing Type: Straight Roller Bearing
SKU: 51-04201-70-1
Caster Weight: 8.2 lbs.

Product Description

This 4-inch by 2-inch 51 series kingpinless caster, is a reliable and cost-effective solution for demanding industrial applications. Renowned for its durability and minimal maintenance requirements, this caster is a valuable investment that reduces downtime and maintenance costs. Designed to withstand abusive environments with prevalent shock loading, it offers a tough and resilient performance. The swivel section of the caster features heat-treated inner and outer rings, securely aligned by high-quality hardened 3/8 inch ball bearings. This construction ensures exceptional strength and smooth operation even under heavy loads. The kingpinless style caster is particularly favored for applications where manual ergonomic operation is crucial, thanks to its effortless swiveling capability. The hardened alloy swivel sections and robust formed and welded legs provide outstanding strength and durability, making the Series 51 caster ideal for challenging industrial environments.

In addition, the Mold-On Rubber wheel combines the strength and resilience of rubber with a robust wheel core for exceptional performance. With superior traction, shock absorption, and non-marking properties, these caster wheels provide smooth and controlled movement while protecting floors. Engineered to withstand heavy loads, they offer durability and longevity, thanks to the securely bonded mold-on rubber tread and solid wheel core. Packed with our straight roller bearings, which are most effective for heavy loads, and are a great option when facing excessive thrust loading, these casters are rated for 350 lbs.

Description

This 4-inch by 2-inch 51 series kingpinless caster, is a reliable and cost-effective solution for demanding industrial applications. Renowned for its durability and minimal maintenance requirements, this caster is a valuable investment that reduces downtime and maintenance costs. Designed to withstand abusive environments with prevalent shock loading, it offers a tough and resilient performance. The swivel section of the caster features heat-treated inner and outer rings, securely aligned by high-quality hardened 3/8 inch ball bearings. This construction ensures exceptional strength and smooth operation even under heavy loads. The kingpinless style caster is particularly favored for applications where manual ergonomic operation is crucial, thanks to its effortless swiveling capability. The hardened alloy swivel sections and robust formed and welded legs provide outstanding strength and durability, making the Series 51 caster ideal for challenging industrial environments.

In addition, the Mold-On Rubber wheel combines the strength and resilience of rubber with a robust wheel core for exceptional performance. With superior traction, shock absorption, and non-marking properties, these caster wheels provide smooth and controlled movement while protecting floors. Engineered to withstand heavy loads, they offer durability and longevity, thanks to the securely bonded mold-on rubber tread and solid wheel core. Packed with our straight roller bearings, which are most effective for heavy loads, and are a great option when facing excessive thrust loading, these casters are rated for 350 lbs.

Additional information

Weight 8.2 lbs
