6x3 T/R Polyurethane Maintenance Free Swivel Caster

SKU: 87-06302-61-1

6x3 T/R Polyurethane Maintenance Free Swivel Caster

Caster
  • Load rating of 1640 lbs.
  • Overall height of 9.5 inches
  • T/R 85A PU Wheel - Industrial strength with a softer touch, high tear and debris resistance, moderate solvent and oil resistance. (Shore 85A Hardness)

Features

Easy SwivelErgonomic CastersFlat Faced CastersMaintenance Free Casters
CAD DOWNLOAD

Specifications

Series
87
Capacity
1,640
Overall Height
9.5"
Bearing Type
Precision Ball Bearing
Wheel Material
T/R Polyurethane
Wheel Diameter
6"
Wheel Width
3"
Wheel Configuration
Single Wheel
Caster Material
Steel
Caster Style
Swivel Caster
Caster Type
Maintenance Free
Swivel Radius
6.18"
Swivel Lead
3"
Bolt Size
0.5
Top Plate Size
6 x 7.5
Bolt Hole Pattern
4.5 x 6

Description

This 6-inch by 3-inch 87 series caster utilizes a dual (precision sealed ball) bearing design, enabling smooth and easy rotation. The dual precision sealed ball bearings with hardened raceways help reduce push force when moving the cart from a stopped position while the wheels are not all parallel. Combined with a T/R 85A polyurethane wheel, this caster is a versatile solution that brings industrial-strength performance with a softer touch. This specialized formulation is engineered for easy and quiet rolling, making it an ideal choice for a wide range of applications. With its high tear and debris resistance, this wheel ensures exceptional durability and longevity. While offering moderate solvent and oil resistance, it is important to note its lack of water resistance and unsuitability for hot and humid environments due to the risk of microbial attack. Featuring precision sealed ball bearings, the caster provides quiet operation and requires no maintenance, all with a load rating of 1640 lbs.
