6x3 Laminated Phenolic Rigid Caster

CasterHeavy Duty Casters: 5,000 lbs to 14,999 lbsRigid Casters

Load rating of 2500 lbs.
Overall height of 8.5 inches
Laminated Phenolic - Wheel made from layers of phenolic resin, offering high load capacity, impact resistance, and resistance to chemicals and solvents.

Features

Flat Faced Casters

Specifications

Series

Capacity

2,500

Overall Height

8.5"

Bearing Type

Straight Roller Bearing

Wheel Material

Laminated Phenolic

Wheel Diameter

Wheel Width

Wheel Configuration

Single Wheel

Caster Material

Steel

Caster Style

Rigid Caster

Bolt Size

0.5

Top Plate Size

6 x 7.5

Bolt Hole Pattern

4.5 x 6

Temp (Continuous)

-50 to 300

Temp (Intermittent)

-50 to 300

Description

This 6-inch by 3-inch 80 series extra heavy duty caster, is meticulously engineered to withstand the most abusive applications. The laser-cut formed legs provide additional strength, making them ideal for applications with side loading or skidding. Components are heat treated to achieve a hardness of 40 + 2 Rc. With exceptional strength and reliable construction, these fixed 80 Series Extra Heavy Duty Casters are the perfect choice for rugged industrial applications. Laminated Phenolic Packed with our straight roller bearings, which are most effective for heavy loads, and are a great option when facing excessive thrust loading, these casters are rated for 2500 lbs.
