12x200 x 8 Pneumatic Rubber Swivel Caster

SKU: 61-12409-78-1

12x200 x 8 Pneumatic Rubber Swivel Caster

CasterMedium Heavy Duty Casters for 900, 1000, and Up to 1,999 lbsSwivel Casters
  • Load rating of 1200 lbs.
  • Overall height of 15.5 inches
  • Pneumatic Rubber Wheel - Rubber tire, providing excellent shock absorption, traction, and smooth rolling on uneven surfaces.

Features

Kingpinless CasterPneumatic Casters

Specifications

Series
61
Capacity
1,200
Overall Height
15.5"
Bearing Type
Precision Tapered Bearing
Wheel Material
Pneumatic Rubber
Wheel Type
Semi Pneumatic
Wheel Diameter
12"
Wheel Configuration
Single Wheel
Caster Material
Steel
Caster Style
Swivel Caster
Caster Type
Kingpinless
Swivel Radius
9.71"
Swivel Lead
3.5"
Bolt Size
0.5
Top Plate Size
4.5 x 6.25
Bolt Hole Pattern
2.438 x 4.938 Slotted to 3.375 x 5.25

Description

This 12-inch by 200 x 8-inch 61 series kingpinless caster, is a highly utilized and reliable industrial solution that offers exceptional value for rugged applications. This caster is renowned for its simplicity and ability to withstand demanding industrial environments with prevalent shock loading. The swivel section features heat-treated inner and outer rings, precisely aligned using high-quality 1/2 inch hardened ball bearings. This robust construction provides outstanding strength and ensures smooth operation even when swiveling under heavy loads. The kingpinless style caster is particularly sought after when manual ergonomic operation is required. Its design and functionality make it a preferred choice for industrial applications. With wheels that mimick car tires, Pneumatic Casters feature rubber wheels around a metal hub, providing exceptional performance. They excel in moving fragile loads with minimal jarring on various surfaces including grass, pavement, and industrial floors. With quiet operation and load cushioning, they offer protection to both loads and floors. Constructed with hot forged steel and double row ball bearing swivels, these casters ensure durability and a long service life. The pneumatic tires cushion the load, absorb shocks, and effortlessly roll over obstructions. Featuring our precision tapered bearings, the wheels are capable of absorbing excessive side thrust loading and can be used where high speed operation is essential, all with a load rating of 1200 lbs.
